Small Duty High Base Horizontal Handle Toggle Clamp MISUMI MC01-2B
/ GH-201-H
Quick Release Horizontal Hold Down Handle Toggle Clamp MISUMI
MC01-2B / GH-201-H
Features:
Quick release, small holding capacity, high base
Application:
Welding, machining, checking fixture, assembly fixture,
woodholding, metal holding, workholding clamps
| Weight (g) | Holding Capacity (kg) | Bar Opens (º) | Handle Opens (º) | Spindle Supplied |
| 140 | 40 | 90 | 75 | GH-FC-053808 |
Automobile Industry
1. Production of various automobile interior accessories:
1) Dashboards, etc. (using PP, ABS materials); used as clamping
fixtures for "casting molds";
Main application models: 431,40341.
2) Dashboards, etc. (using PU materials); used as clamping fixtures
for "foaming molds"; and
Main application models: 40341,10448,20448,702-D etc.
3) Inspection of interior accessories is used as positioning and
locking fixtures for testing jigs;
Main application models: MISUMI MC01-2B / GH-201-H,
101-D,12130,12135,302-F etc.
4) Lining (with leather, wool cloth materials) is used as fixing
fixtures for fixing upper and lower molds on the press.
Main application models: 40370,40380.
2. The rivets and welds on the chassis of small cars such as
minibuses, jeeps and sedans are used as positioning and locking
fixtures for riveting and welding jigs.
Main application models: 702-C,702-D,702-K,303-E,304-H etc.
3. In the production of partially refitted auto bodies, the manual
toggle clamp is used in the assembly and welding of auto bodies.
Main application models: F clamps and Toggle Pliers.
4. Manual toggle clamps are used for local spot welding during
assembly in small and medium sized automobile plants.
Main application models: Toggle Pliers.
5. Production of luxurious minibus and bus bodies:
1) Body keel welding is used as fixtures for welding jigs.
Main application models: 702-D,10247,12265,11412 etc.
2) For welding of the outer metal plate of the car body, manual
toggle clamps are used as fixtures.
Main application models: F clamps and Toggle Pliers.
3) For the adhesion of super-luxury bus and minibus interior
accessories, manual toggle clamps are used for adhesion and
fixation between interior accessories and auto bodies.
Main application models: F clamps.
Note: Manual toggle clamps can be used for all products or parts
that are similar to the above categories regarding the
manufacturing materials and production methods and have the
characteristics of continuous mass production.
Electronics Industry
1. Manual toggle clamps are used in the assembly line and testing
process of small motors and electric tools.
Main application models: MISUMI MC01-2B / GH-201-H,
12050,12050-U,101-A,102-B,301-A,304-C etc.
2. The metal shell of various electrical appliances, such as water
heaters, microwave ovens, air conditioners, refrigerators,
cabinets, and chassis is quickly clamped on the "welding molds" as
a fixture.
Main application models: 11412,203-F,225-D,21502-B,102-B,101-D
3. Electrostatic spraying equipment and manual toggle clamps serve
as accessories, mainly for barrel cover opening and closing. (In
the spraying production line, a manual toggle clamp is sometimes
used to fix the processed object).
Main application models: 40323,431,40341,451 etc.
4. One of the production equipment for PCB boards, jet-soldering
machine, with manual toggle clamp on the conveyor chain fixture.
Main application models: MISUMI MC01-2B / GH-201-H,
101-A,201,20300,21800 etc.
5. The manual toggle clamp is used as a component on the
"mechanical winding machine" for fixing the core frame.
Main application models: 12130,12130-A etc.
Horizontal Toggle Clamp
When the handle is in the horizontal position, this toggle clamp is
in the locked position. As the handle moves towards the table, its
securing arm locks into place. Commonly, this is used when there
are height limitations to machinery. Plus, don’t forget to mount it
to a table.
.Installation base divided into two parts and relatively rotating,
easy to install
.Fast and flexible loading and clamping with stable clamping force
.Adjustable compression force height suitable for different height
of door plank and frame
.Safe and convenient to operate
.High effciency
.Small size with strong tightly force
.Handle is wrapped with rubber, easy to operate
.Greatly reducing operation time for processing, assembling,fixing
| Q'TY PCS | 1-100 | 101-500 | 501-1000 | 1001-2000 | 2001-5000 | 5000+ |
| EST.DAYS | 1-3 | 3-5 | 5-7 | 7-15 | 15-25 | 25-35 |
| Brand | JOINTECH |
| Model | MISUMI MC01-2B / GH-201-H |
| Bar Type | U Bar |
| Base Type | Flanged |
| Handle Type | Straight |
| Clamping Type | Horizontal |
| Operation Type | Hold Down Quick Clamping |
| Standard / Non | Standard |
| Holding Force (LBS) | 80 |
| Spindle Standard | mm/inch |
| Material | Metal; SUS#201; SUS#304; SUS#316; |
| Finish | Silver; Natural; Red / Blue / Black / Orange Dipped Grip; |
| Design | OEM & ODM |
| Price Term | Ex-works; FOB Shenzhen; CIF; CFR; DDU; DDP; DA; DP; |
| Sample Request | F.O.C. / $1USD |
| Stock Status: (PCS) | 1500 |
